Conquest 304 Stainless Steel Wedge Anchors for Concrete 3/4” x 5-1/2”

Product Details

• Color: Silver
• Item Weight: 7.1 pounds
• Number of Items: 10
• Unit Count: 10 Count
• Part Number: CWA34-512SS4
• Thread Size: 1/2-13
• Exterior Finish: Stainless Steel
• Manufacturer Grade: Grade 304
• Screw Head Style: Chamfered
• Fastener Type: Anchor Bolt
• Thread Type: Unc
• Thread Style: Coarse
• Item Hardness: Grade 8.8
• Head Type: Wedge
• Thread Class: UNC
• Compatible Groove Diameter: 0.75 inches
• Grade Rating: 304
• Material Type: Stainless Steel
• Metal Type: Stainless Steel
• Finish Types: Brushed
• Item Highlight: (10-Pack), Heavy Duty 3/4 Anchor Bolts for Outdoor Concrete Fastening, Residential, and Light Commercial Projects
• Item Diameter: 0.75 inches
• Size Name: 3/4" x 5-1/2"
• Number of Pieces: 10
• Fastener Size: 3/4" x 5 1/2"
• Thread Coverage: Partially Threaded
• Outside Diameter: 0.75 inches
• Set Name: No Set
• Model: CWA34-512SS4

About this item

• SPECS - Stainless Steel Wedge Anchors
• Diameter: 3/4 inch
• Length: 5-1/2 inch
• Thread Length: 3-1/8 inch
• Drill Bit Size: 3/4 inch
• Torque: 110 ft/lbs
• Material: 304 Stainless Steel
• Quantity: 10-Pack
• TYPE 304 STAINLESS STEEL - Made from robust 304 stainless steel, Conquest Fasteners’ concrete wedge anchors are built for dependable, long-lasting performance in concrete fastening applications, including outdoor and corrosive environments.
• PROFESSIONAL ANCHORING APPLICATIONS - Built for anchoring steel columns, beams, HVAC units, generators, warehouse racking, pipe brackets, lighting fixtures, stair railings, and other equipment to concrete in residential and commercial applications.
• SECURE HOLD IN CONCRETE - These stainless steel concrete anchors feature a precision-engineered taper and expansion clip that help the anchor expand firmly inside the hole, delivering reliable holding strength under load.
• DRILL, SET, & TIGHTEN - Designed for fast, simple installation in solid concrete. Drill a hole matching the anchor’s nominal diameter, insert the wedge anchor, and tighten to expand. Each anchor is clearly marked for easy length identification.
